UPS ICA SE2102C31 (20000VA/18000W) (TKDN)

UPS ICA SE2102C31 (20000VA/18000W) (TKDN)


Description : UPS SE2102c31
Capacity : 2000 VA / 18000 W
AC Voltage : 3 PHASE, 208 ~ 478 V
AC Frequency : 45 ~ 65 Hz
AC Protection : 63 A
DC Voltage : 240 V
DC INT Battery : EXTERNAL BATTE, 7 AH)RY BANK (2 x 20 x 12 V
DC Protection : MCB
CHG Topology : SWITCHING REGULATION
CHG Floating Voltage : 272 V
Inv Out Waveform : SINE WAVE
Inv Out Distorsion : < 2% THD
Inv OutTopology : ONLINE DOUBLE CONVERSION
Inv Out Voltage : 220 ± 1% V
Inv Out Frequency : 50 ± 1% Hz
Inv Out Efficiency : ? 90 %
Transfer Time When AC In Loss : 0 ms
Static Transfer Switch : 0 ms
Back Up Time : 10 min
Buzer AC In Abnormal : INTERMITTENT WITH 4 SECOND INTERVAL
Buzer Battery Low : INTERMITTENT SOUND WITH 1 SECONDS INTERVAL
Opera Temp : 0 - 40 °C
Dimension (DxWxH) : 540 x 255 x 635 (UPS) 620 x 250 x 620 (Ext. Batt Bank)
Weight : NETTO 40 Kg (UPS); 122 Kg (Ext. Batt. Bank) , BRUTO 49,2 Kg (UPS); 127 Kg (Ext. Batt. Bank)
